Time Alpe D’HUEZ Disc Frameset
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Ut elit tellus, luctus nec ullamcorper mattis, pulvinar dapibus leo.
The Story
Notice: TIME framesets on backorder
Please take note, framesets that are on backorder have a lead time of approximately 14 days from date of order.
We appreciate your patience and understanding.
————————————————————————————————————————————————-
The Evolution of Alpe d’Huez
Alpe d’Huez is more than a climb in Le Tour. Helicopters, police escorts, blue smoke, screaming face-painters, and a crowd of 300,000 cycling fans guarantee that every visit to this legendary summit will be crowned forever in glory. It’s this unmistakable marriage of history, spectacle, colossal effort, sportsmanship, and beauty that is woven into every Alpe d’Huez frame we make. To ride the new TIME Alpe d’Huez disc is to enjoy something that eludes description that can’t be duplicated by any other bike. This is the Ultimate Road Bike.
What’s Included
- DEDA S DCR Headset for Semi & Fully-Integrated Cockpits
- Front and Rear Thru Axles
- Alloy Bottle Bolts
- Integrated Seat post Clamp
- (1) Derailleur Hanger
- Single Cover and Drivetrain Conversion Kit
Technical Details
| FRAME MATERIAL BCS Carbon Fiber, Vectran™ and Dyneema® |
THRU AXLES 12x120x1.5mm Pitch F, 12x159x1.5 |
| SIZES X, S, M, L, XL |
SEATPOST DIAMETER ø 27.2mm |
| FORK STEERER TUBE Tapered 1-1/8″ to 1-1/2″ Vectran™ Enhanced |
SEATPOST CLAMP Proprietary ADH Alloy |
| HEADSET BEARINGS Top and Bottom 1-1/2″ (with internal routing compression ring) |
SHIFTING Compatible with Electronic Shifting Systems. Mechanical-compatible frames available by special order. |
| WHEEL SIZE 700c, ETRTO 28-622 |
FRONT DERAILLEUR 1X and 2X Compatible |
| MAXIMUM TIRE WIDTH 28c |
REAR DERAILLEUR Standard Mount |
| BOTTOM BRACKET PF BB386 EVO |
BRAKE TYPE Front and Rear Flat Mount Disc |
| DISC HUB STANDARD 12x100mm FRONT, 12x142mm REAR |
ROTOR SIZE Max 160mm with DM Adapter |
Builds / A look at how customers have built this frame up
